ContentsXAML Syntax

Extensible Application Markup Language (XAML) is a markup language used in markup enabled xButton objects for advanced text formatting such as highlighting, hyperlinks and more. For further information, see the MSDN XAML Overview.


Supported XAML Tags Examples


Supported XAML Tags


The following is a list of supported XAML tags and their attributes:



Tags


Attributes


Page


(Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height,MinWidth, MaxWidth, MinHeight, MaxHeight,)


Border


(Cursor, Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth,MinHeight, MaxHeight, Padding, Background, BorderThickness, BorderBrush)


TextBlock


(Cursor, Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, MaxHeight, Padding, Background, Foreground, TextWrapping, TextAlignment, TextDecorations, FontSize, FontWeight, FontFamily, FontStyle, BaselineAlignment, Text)




(Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, MaxHeight, Source)


Run


(Cursor, Background, Foreground, TextDecorations, FontSize, FontWeight, FontFamily, FontStyle, BaselineAlignment, Text)


LineBreak


no attributes


Span


(Background, Foreground, TextDecorations, FontSize, FontWeight, FontFamily, FontStyle)


Bold


(Background, Foreground, TextDecorations, FontSize, FontWeight, FontFamily, FontStyle)


Italic


(Background, Foreground, TextDecorations, FontSize, FontWeight, FontFamily, FontStyle)


Underline


(Background, Foreground, TextDecorations, FontSize, FontWeight, FontFamily, FontStyle)


InlineUIContainer


(Background, Foreground, TextDecorations, FontSize, FontWeight, FontFamily, FontStyle)


Hyperlink


(Background, Foreground, TextDecorations, FontSize, FontWeight, FontFamily, FontStyle)


Panel


(Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, MaxHeight, Background)


StackPanel


(Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, MaxHeight,



Background, Orientation)


WrapPanel


(Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, MaxHeight, Background, Orientation, ItemHeight, ItemWidth)


Canvas


(Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, MaxHeight, Background, Left, Right, Top, Bottom)


Grid


(Style, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, MaxHeight, Background, ColumnDefinitions, RowDefinitions)


ColumnDefinition


(Width, MinWidth, MaxWidth)


RowDefinition


(Height, MinHeight, MaxHeight)


Polygon


(Width, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, Points)


Polyline


(Width, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, Points)


Rectangle


(IsMouseOver, Width, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight)


Ellipse


(Width, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight)


Line


(Width, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, X1, Y1, X2, Y2)


Button


(IsPressed, Style, Width, Margin, ClipToBound, HorizontalAlignment, VerticalAlignment, Width, Height, MinWidth, MaxWidth, MinHeight, Content)


CheckBox


no attributes


RadioButton


no attributes


ScrollViewer


(Style, VerticalScrollBarVisibility, HorizontalScrollBarVisibility)


SolidColorBrush


(Color)


LinearGradientBrush


(StartPoint, EndPoint, GradientStops)



GradientStop


(Color, Offset)


Style


(TargetType, BasedOn, Resources)


Setter


(Property, Value)


Examples


The following are examples of xButton object XAML text that can be used when Enable markup is selected.



Example 1


<TextBlock>Button with <Hyperlink>Hyperlink</Hyperlink></TextBlock>


This example shows the text "Button with Hyperlink" when used on a markup enabled xButton object.



Example 2


<TextBlock><Run FontWeight='Bold'>This text is </Run> <Run Foreground='Red'>colored red</Run></TextBlock>


This example shows the text "This text is colored red" where 'colored red' is shown in red while the remaining text is shown in black.



Example 3


<TextBlock>This is <Italic>italic</Italic> text and this is

<Bold>bold</Bold> text.</TextBlock>


This example shows the text "This is italic text and this is bold text."



Example 4


<TextBlock>This is <Italic>italic</Italic> text and this is

<Bold>bold</Bold> text.</TextBlock>


This example shows the text "This is italic text and this is bold text."



Example 5


<TextBlock FontSize="32" Padding = "3" VerticalAlignment="Center">Install <Image Cursor="Hand" Source="file://AutoPlay/Images/check.png"/></TextBlock>

This example shows the text "Install" followed by an image. The mouse cursor changes to a hand when you mouse over the image.



Example 6


<StackPanel TextBlock.FontFamily="Tahoma">

<TextBlock Padding="1, 3, 1, 3" FontWeight="Bold">Install</TextBlock>

<TextBlock Padding="9, 6, 30, 7" TextWrapping="Wrap">Click to install the software.</TextBlock>

<Border Height="1" Background="#9ebbdd" />

<Border Height="1" Background="White" />


<StackPanel Margin="1, 7, 0, 3" Orientation="Horizontal">

<TextBlock Margin="7, 0, 0, 0" VerticalAlignment="Center" FontWeight="Bold"><Hyperlink>More Info</Hyperlink></TextBlock>

</StackPanel>

</StackPanel>



This example shows an xButton with the text "Install" in bold, on the next line the indented text "Click to install the software." followed by a separator and a hyperlink labeled "More Info.



Example 7


<Page>

<StackPanel>

<Border Cursor="Hand" BorderThickness="1" BorderBrush="#bdcaea">

<Border.Background>

<LinearGradientBrush EndPoint="1, 0.5" StartPoint="0,

0.5">


<GradientStop Color="#c3d6ff" Offset="0"/>

<GradientStop Color="#eef2ff" Offset="1"/>

</LinearGradientBrush>

</Border.Background>

<Grid>

<Grid.ColumnDefinitions>

<ColumnDefinition Width="*"/>

<ColumnDefinition Width="Auto"/>

</Grid.ColumnDefinitions>

<TextBlock Text="Install" Foreground="#30486e"

FontSize="18" Margin="12,2,2,2"/>

<TextBlock Grid.Column="1" Margin="2,2,12,2"><Hyperlink Foreground="#047c05" FontSize="18">More Info</Hyperlink></TextBlock>

</Grid>

</Border>

<Border Margin="0, 0, 0, 0" BorderThickness="1, 0, 1, 1" BorderBrush="#bdcaea" Background="#eff3ff">

<TextBlock TextWrapping="Wrap" Margin="12, 4, 12, 4"><Run>Click to install the software from D:\install</Run></TextBlock>

</Border>

</StackPanel>

</Page>


This example shows an xButton with a panel within the button containing the formatted text "Install", beside it a hyperlink "More Info" and below the text "Click to install the software from D:\install."
